USB-C Dual Monitor Docking Station - 14-in-1

Product Description

The USB‑C Docking Station (14‑in‑1) transforms a single compatible USB‑C, Thunderbolt™ 3, or Thunderbolt™ 4 port into a full desktop workstation. Designed for users who require expanded video, data, and peripheral options, this docking station supports up to three external displays on Windows systems through 2 × HDMI outputs and 1 × USB‑C video port. The hub includes high‑speed data interfaces, Gigabit Ethernet, multi‑format card readers, and 100W USB‑C Power Delivery input to keep devices powered during operation.

This dock is engineered for laptops that support DisplayPort Alt‑Mode or Thunderbolt technology. Windows devices can operate in full Extend Mode, enabling three distinct external screens. macOS systems do not support MST and operate in mirrored or dual‑extended configurations depending on model limitations.

With 10Gbps USB‑C and USB‑A ports, two USB 2.0 peripheral ports, SD/TF card readers, and a 3.5 mm audio interface, this docking station provides the connectivity needed for multitasking, content creation, conferencing, and mobile productivity. The aluminum‑style housing and compact design make it suitable for office desks, hybrid work environments, and travel.

Key Features

• 14‑in‑1 USB‑C docking station for laptops that support DP Alt Mode or Thunderbolt
• Supports 3 displays on Windows (2 × HDMI + 1 × USB‑C video output)
• HDMI outputs support up to 4K @ 60Hz (device‑dependent)
• 10Gbps USB‑C full‑function port with DP Alt‑Mode
• 3 total USB‑C ports (data + video, depending on port)
• 3 additional 10Gbps USB‑A ports
• 2 × USB 2.0 ports for low‑speed peripherals
• Gigabit Ethernet for stable wired networking
• 100W USB‑C PD input (up to 85W passthrough charging to laptop)
• SD and TF card readers
• 3.5 mm audio/microphone combo port
• Compatible with Windows laptops and Thunderbolt/USB‑C devices
• macOS not compatible with triple‑extended MST mode

Key Specifications

• Video Outputs:
• HDMI 1: up to 4K @ 60Hz
• HDMI 2: up to 4K @ 60Hz
• USB‑C Video: DP Alt‑Mode (resolution varies by device)
• USB Ports:
• 1 × USB‑C full‑featured (10Gbps + video)
• 2 × USB‑C (10Gbps data)
• 1 × USB‑A (10Gbps)
• 2 × USB‑A (USB 2.0)
• Networking: 1 × RJ‑45 Gigabit Ethernet port
• Audio: 3.5 mm audio/mic combo jack
• Card Readers: SD + TF
• Power Delivery: 100W input, up to 85W laptop passthrough
• System Support: Windows (MST supported), macOS (MST not supported)
• Materials: Aluminum‑style shell with reinforced connectors
• Color: Space‑gray/black (varies by batch)

In the Box

• 1 × 14‑in‑1 USB‑C Docking Station
• 1 × USB‑C host cable
• 1 × User documentation
